Transformer Pressure Vacuum Gauge With Contacts

Views: 0
Date: 2024-05-20 22:16:40
Category: IEEE Accessories

Parameters

- Working Temperature: -40~70℃

- Relative Humidity: Not higher than 85%

- Diameter: Φ100mm & Φ150mm

- Accuracy: 1.6 & 2.5

- Contact Power: YXC magnetic model 1A.30VA

- YX direct model：0.7A.10VA

- Max.Working Voltage: AC380V, DC220V

- Control Model: Single min. & max. limit, dual min. & max.limits.

General

The electrical contact pressure gauge is suitable to measure the pressure ofgas or liquid that is non-corrosive to brass, non-explosive, andnon-crystalline.

It consists of general pressure gauge and electrical contacts, and it's usedto achieve the dual control of max. and min. pre-set pressure and give thealarming signals.
