15/25kV 100A Transformer Wye-Delta Transfer Switch

Views: 0
Date: 2024-05-20 21:49:00
Category: IEEE Accessories

The transfer switch is designed for use in distribution transformers to change the wingding connection group from Wye to Delta.

The switch body, rotor, and shaft are made of a high strength, glass-filled thermoplastic material. The operating shaft is sealed against leakage by two high temperature resistant O-Rings.

The transfer switch is no excitation switch, operate it just in no load condition.
